Machine Dimension

Overall length (mm)

4270

Overall Width (mm)

1850

Overall Hight (mm)

250

Wheelbase (mm)

1550(optional1800)

Turning Radius (mm)

2750

Tread (mm)

1535

Effective Ground Clearance (mm)

1200( Axle Housing )

Minimum Ground Clearance (mm)

1200(optional 1500)hign gound clearance

Engine

Horse Power (HP)

88hp

Type

Quanchai /changchai, Water cooled 4 cycle, 4 cylinder Standing Diesel engine

Total Displacement (L)

1.028

Rated Output (Kw (PS) / rpm)

16.5(22.4)/3600

Starting Method

Key Starter

Fuel Tank Capacity (Liter.imp.gal)

24/5.3

Transmission Type

4WD.4WS

Steering System

Full Hydraulic Power Steering

Gear System

Hydrostatic Transmission   System

Number of Pumps

1

Travelling Speed (kmph/mph)

Travelling 0-10/0-6.2

Brakes (Also use Parking brake)

Wet, multi disk, mechanical type

Tyres (front / Rear)

Diameter1.4mwide0.13m, Diameter1.2mwide0.12m. Diameter0.9mwide0.12m, Diameter1.0mwide0.20m

Spray Tank Capacity (Liters / imp.gal)

700/800L/1000L

Agitation Method

Jet Agitation

Spray Pump Type

3 Position Diaphragm Pump

Pump Revolution (rmp)

540

Suction Capacity (L/min &imp.gal/min)

54/12

Max.Pressure (map/psi)

4/580

Spray boom unit

Both Swiveling Booms Opened Close Individually

Nozzle Type

2 Way Triple Action

Nozzle Discs

Ceramic 80, Hollow Cone Both

Numbers of Sections

3

Fertilizer applicator撒肥机宽度

10-25width

Spray Width( m)

12M,14m,16m,18m,20m
