Type

/

Suspended type

Matched Power

HP

75--100

Dimension（L×W×H）

mm

2320*3900*1445

Working Speed

km/h

4-6

Working Efficiency

hm２/h

1.44--2.16

Row Spacing

mm

150（Adjusted）

Number of Rows

24

Wide

m

3.6

Type of seed metering / fertilizer applicator

/

Iron outer grooved wheel / outer grooved wheel

Number of seed metering / fertilizer applicators

个

24/24

Driving mode of seed metering / fertilizer applicator

/

Ground wheel drive

Volume of seed / fertilizer box

L

410/430

Displacement adjustment mode

/

Adjustable screw type

Transmission mechanism type

/

Chain drive

Type of ditcher

/

Double disc type

Number of openers

个

24

Depth adjustment range of ditcher

mm

40-80

Ground wheel type

/

Rubber tire

Diameter of ground wheel

mm

680

Type of soil cover

/

Overburden ring

Type of suppressor

/

Press roll
